AXIS FD120 - 64mm
The AXIS FD120 represents the highest-grade fire door core in our product line, engineered to provide exceptional 120-minute fire resistance for the most demanding safety applications. This 64mm thick, 3-layer particle board core combines advanced materials with rigorous engineering to deliver superior fire protection while maintaining excellent workability for door fabrication.
Key Features
AXIS FD120 3-layer particle board developed as a high performance door core
For internal (non-structural )use in domestic and commercial
premises in dry conditions
Smooth, suitable for Veneer, Laminate, PVC, and Paint.
Produced with recycled softwood, hardwood, and Vermiculite resin.
BS 476: Part 1987 :22, BS EN 2008/1:2000-1634 & BS EN 1:1999-1363
BS476: Part 1987
IFCC - CERTIFICATE NO : 1621
CCS - CERTIFICATE NO : PC 293
PAR/21119/02 (Note: Extra "1" in original)
Resist Fire up to 120 Minutes
100% Recycled Product.
850 Kgs / m3 ± 10
48 kg m2
1.0 MPa
64mm ± 0.3
E1 <7.9mg / 100g
915213544mm
1045215544mm
1220244044mm
Single Doors (Unglazed 34dB/Rw Double Doors(Unglazed 36dB/Rw)
(Note: Glazed values missing in original)
0.42 MPa
